Giben Smart 75 CNC Panel Saw (2004) - $7,250 (Omaha)

Giben Smart 75 CNC Panel Saw (2004) 1 thumbnail

8800 F St near 84th

google map

condition: good

make / manufacturer: Giben

model name / number: Smart SP75

more ads by this seller

QR Code Link to This Post

Used Giben SmartSP75 Panel saw. Does operate but has been sitting in storage for 10+ years. The reason we took it out of service was because it needed new plc updates. We found a Holzma that worked a lot better for us. It is all taken apart and crated to be ready to ship. It runs off of 230 Volt 3 phase. Giben said that they still has part available for this model.

Machine Specifications:
Cutting Length: 3800mm (12.5')
Blade Projection: 75mm (2.95")
Maximum Depth of Clean Cut: 64mm (2 ½")
Gripper Opening: 65mm (2 9/16")

Main Saw:
Blade Diameter: 320mm
Motor Power: 15 HP
Voltage: 230V, 60Hz, 3 Phase

Scoring Saw:
Blade Diameter: 180mm
Motor Power: 1.5 HP

Saw Carriage:
Traverse System: Brushless AC with inverter
Feed Speed: 5 to 50 m/min (16 to 131 ft/min)
Return Speed: 60 m/min (131 ft/min)

Alignment & Positioning:
Pneumatic Locking & Automatic Positioning Side Aligner (Behind Cut Line)
Side Aligner Stroke: 1220mm (48")
Minimum Width to Side Align: 60mm (2.4")
Pneumatic Quick-Release Saw Blade Hubs

Pusher System:
Stroke Length: 3350mm (11')
Drive System: Brushless AC motor with inverter
Guidance: Round bar system
Advancing Speed: 0.8 to 25 m/min
Return Speed: 40 m/min
Floating Grippers: 7 units
Roller Profiles Under Pusher
